Supermarkets P10 32*16 9500K Outdoor Fixed LED Display
Place of Origin | Shen zhen China |
---|---|
Nazwa handlowa | AVOE LED |
Orzecznictwo | CE RoHS |
Model Number | AE-P10OFRGB |
Minimum Order Quantity | 5sqm |
Cena | negotiable |
Packaging Details | Flight case, Plywood case. |
Delivery Time | 10 working days after receiving the payment |
Payment Terms | T/T, Western Union, MoneyGram, L/C |
Supply Ability | 10K sqm per month |

Skontaktuj się ze mną o darmowe próbki i kupony.
WhatsApp:0086 18588475571
WeChat: 0086 18588475571
Skype: sales10@aixton.com
Jeśli masz jakiekolwiek obawy, oferujemy 24-godzinną pomoc online.
xName | Outdoor Advertising LED Display | Resolution/mm | 10mm |
---|---|---|---|
Pixel density/pixels/m² | 10000/m² | Module resolution | 32*16 |
Horizontal view angle | 120(degrees) | Vertical view angle | 60(degrees) |
Cabinet size | 960*960mm | ||
Podkreślić | 9500K Outdoor Fixed LED Display,32*16 Outdoor Fixed LED Display,9500K p10 display board |
P10 Outdoor AVOE Advertising LED Display screen For Commercial Center / Supermarkets
Features
1. Can repair each led lamps, so the cost of maintain is lower, and easy to repair.
2. Big viewing angle to 120 degree at horizontal line, 60 degree at vertical line, you can see at every angle at this range, no picture change, no color excursion.
3. To pictures and character, have clear, exquisite and real display effect.
4. High intensity and can be adjusted, so can meet the request of the customers according the application environment.
5. Thermostatically controlled fan: Unique temperature control design works only when the temperature is higher than the pre-set temperature.
6. Low power consumption and good performance of dissipating heat make it work normally in the condition of no air condition.
7. New mask design makes LED light almost zero reflection, which ensures the screen displaying effect.
Aplication:
Commercial Center, Advertising- Information Publish Board, Commercial Street, Railway Stations, Airports, Bus Stations, Subway, Shopping Malls, Supermarkets, Hospitals, Media Centers Etc.
Parameters
Resolution/mm | 10mm |
Pixel configuration | 1R1G1B |
Pixel density/pixels/m² | 10000/m² |
Module resolution | 32*16 |
Module size/mm | 320*160 |
View distance | 9-400m |
White balance brightness | >8000cd/㎡ |
Color temperature | 6500K-9500K |
Horizontal view angle | 120(degrees) |
Vertical view angle | 60(degrees) |
Signal Process bit | 10 or 16bit |
Grey process | 1024x1024x1024 16834x16834x16834 65536x65536x65536 |
Control distances | CAT6 cable:<100 m; Single mode fiber:<10 km |
Driving mode | Constant driving current |
Scanning mode | 1/4 scan |
Frame rate | 60Hz |
Refresh frequency | >2880Hz |
Control mode | Computer synchronous |
Brightness adjusted range |
Manual, automatic operation, stepless continuous adjusted 255 steps. No grey loss |
Out of control point | <1/10000 |
Working hours | ≥72hours |
Mean Time Between Failure | >5000hours |
Life time | 100000hours |
Life-all-white(brightness halving) | 50000hours |
Environment temperature range | Operating temperature range: -20-45℃ |
Maximum power:/㎡ | <900W |
Average power:/㎡ | <350W |
Self-check technology |
LED spot self-check, communications check, power check, temperature monitor(need customization) |
Remote monitoring |
Remote supervision and control, record potential fault, send out warning signs to the operators.(need customization) |
Software environment | Windows (2007/XP/Vista/7/8/10) |
Luminous point width between centres | Deviation<3% |
Brightness uniformity | <10% |
Color uniformity(chromaticity coordinate) | ±0.003 |
Power supply request | AC85-264V(50Hz-60Hz) |
Contrast | (1000:1) |
System protection | Moisture-proof, dust-proof,high temperature protection,anti-corrosion,anti-burning,anti-static,anti-vibration |
Humidity(working) | working:10-95% |
Humidity(storing) | storing:10-95% |
